Agricultural drone

Drone DJI AGRAS T30

  • Drone DJI AGRAS T30

DJI AGRAS T30 Agricultural Drone Pricing

Drone-only package: 245,000 THB
(Battery and charging station not included)

Optional accessories

  • T30 battery: 56,000 THB
  • T30 battery charging station: 33,000 THB
  • T30 fertilizer spreading kit: 23,000 THB

Starting price
245,000 Baht
Calculate annuity Test drive Dealer Download catalog
HIGHLIGHT

Application features

Efficency

  • Drone DJI AGRAS T30

    Maximum operating flight speed of up to 7 m/s

    With a maximum spray width of up to 9 meters, enabling fast and efficient operation

  • Drone DJI AGRAS T30

    16 spray nozzles

    Produces a fine spray with adjustable flow rate based on flight speed, ensuring thorough and even coverage.
    Equipped with 8 automatic air‑release valves to maximize spraying efficiency.

  • Drone DJI AGRAS T30

    6 propellers

    Helps the drone maintain excellent stability and smooth flight performance.
    Even if one propeller malfunctions, the drone can continue flying safely, ensuring uninterrupted operation.

  • Drone DJI AGRAS T30

    30‑liter liquid tank capacity

    Enables continuous spraying across the entire field.
    Equipped with a filter to prevent impurities from clogging the nozzles and a float-based liquid level measurement system that provides milliliter-level accuracy for precise volume control.

  • Drone DJI AGRAS T30

    Dual high‑pressure pump system

    Delivers full spraying power up to 7.2* L/min, ensuring consistent, stable, and precise application of various substances.

    *When operating in manual control mode

Durability

  • Drone DJI AGRAS T30

    Dust‑ and water‑resistant

    With International Protection Standard (IP67) certification, providing robust dust and water resistance for reliable operation in harsh working conditions.

Convenience

  • Drone DJI AGRAS T30

    New remote controller design

    Easy system setup with RTK positioning, supporting centimeter-level accuracy
    Supports 3D spraying system (tree‑specific spraying)
    Can control up to 5 drones simultaneously**
    Maximum control range of 2 km
    Smart nearest return-distance calculation when liquid level is low, enabling better mission planning and helping save battery power

  • Drone DJI AGRAS T30

    Easy to fold and convenient to transport

    The arms are built from high‑durability carbon fiber, featuring a foldable design to save space and make transportation easier.

  • Drone DJI AGRAS T30

    High‑resolution camera

    Equipped with two high‑resolution cameras at the front and rear of the drone, offering 720p HD clarity.
    Each camera is supported by 4 LED lights, providing clear and wide visibility even in low‑light conditions.

  • Drone DJI AGRAS T30

    New radar system

    360-degree omnidirectional radar system protects both horizontal and vertical directions, ensuring safer operation.
    The drone can detect and avoid obstacles within 20 meters and will automatically stop before collision at 3.5 meters, enhancing safety during flight.

  • Drone DJI AGRAS T30

    Latch‑type arm locking system

    Equipped with an arm lock warning system that alerts you if the arms are not properly locked, enhancing ease of use and helping reduce the risk of accidents.

Great value for money

  • Drone DJI AGRAS T30

    New charging station and battery

    Fast‑charging system, capable of charging two batteries simultaneously
    Charging time: approximately **12 minutes per charge** for the AGRAS T30**

  • Drone DJI AGRAS T30

    New charging station and battery

    High‑quality lithium polymer battery with a lifespan of up to 1,000 charge cycles
    Remaining battery level monitoring to prevent power loss during flight
    Automatic discharge** when not used for over 7 days
    Built‑in self‑cooling system, supporting continuous charging without battery rest time

Specifications
Fuel capacity (liters) 30
Spray radius (m) (meter) 4.0 - 9.0
Drone size
Size when spreading wings (millimeter x millimeter x millimeter) 2,858 × 2,685 × 790
Size with wings folded (millimeter x millimeter x millimeter) 1,170 × 670 × 857
Aircraft system
The heaviest weight to take off (including spraying agent) (kilograms) 66.5
Full tank flight time/Empty flight time (min/1 battery) 7.8/20.5
Max working speed 7
Maximum flight speed (Flight maintenance mode : P) (meter/second) 10
Maximum flight speed (Altitude Hold Mode : A) (meter/second) 10
Maximum flying distance 100
Recommended temperature range for use (degrees) 0 - 45
Remote control system
Remote model RM500-ENT
volts (volts) 51.8
External remote control battery (mAh/hour) 4,920
Internal remote control battery (mAh/hour) 5,000
Maximum control distance (km) 4
Power consumption (watts) 18
Calculation of the nearest return distance when the substance is almost exhausted มี
Remote control charger
Output voltage (volts) 8.7
Maximum output current 6
Power (watts) 57
Battery
Battery model BAX501-29,000mAh-51.8V
Voltage (volts) 51.8
Battery protection level IP54
Battery capacity 29,000
Weight 10.2
Battery charger
Rated input voltage (volts) 100 - 240
Rated input current (ampere) 32
Number of batteries per charge (lump) 2
Charging mode 1 ระบบ (แบบชาร์จเร็ว)
Rated output voltage (volts) 58.8
Total maximum power output (watts) 7,200
Radar details
Radar model RD2424R
Operating frequency (GHz) 24.05 - 24.25
Transmitting power (mW) <100
Anti-collision system
Obstacle detection direction Spherical omnidirectional
Protection level for radar devices IP67
Spray nozzle
Spray nozzle model XR11001VS
Estimated spray volume (liter/min) 7.2
Number of nozzles (heads) 16
Size of the dropper head (millimeter) 0.13-0.25 (ขึ้นอยู่ลักษณะการใช้งานในพื้นที่จริง)
