Tractor

M-Series

Deep plowing with powerful and robust performance.

M Series tractor is designed to handle tough and demanding field operations. In addition to its powerful engine performance, it also maintains excellent maneuverability with a transmission system specially designed for KUBOTA tractors.

Starting price

1,090,000 Baht

horsepower

70.00 horsepower

Calculate annuity

Test drive

Dealer Download catalog

Gallery M7040-B KIS

Application features

Performance

Powered by a V3307-DI diesel engine featuring a center direct injection system for efficient and powerful performance.

3,331 cc, 70-horsepower engine with fuel injected directly at the center of the piston head, ensuring complete combustion and improved fuel efficiency.
Synchromesh transmission.

8 forward and 8 reverse gears allow smooth shifting without stopping the tractor, ensuring agility, faster operation, and maximum efficiency.
Synchro shuttle transmission.

Forward and reverse direction changes without stopping the tractor, enabling faster operation and making it ideal for tasks that require frequent direction changes.
Full hydraulic power steering.

Easy steering with minimal effort, featuring an adjustable steering wheel height to suit the operator’s ergonomics.
4 WD system

With 4 WD system integrated with a rear differential lock, it maximizes the tractor’s driving power. Ideal for field plowing and dozing operations that require high traction and strong driving force.

Durability

Implement lifting system.

“The lower link is reinforced with a steel plate up to 19 mm thick, providing high resistance to pulling and shock loads. The side chains are designed with a larger thread diameter of 20 mm, increasing strength by up to 20%. It also features a hexagonal adjuster, making implement adjustment easier and more convenient.
Implement lifting system.

The lift rod features an enlarged thread diameter of 30 mm, increasing strength by 50%, comparable to larger tractor models.
Sealed helical gear front hub.

A distinctive feature of KUBOTA tractors, designed to withstand high torque and deliver superior driving power. The sealed hub system prevents water and dust from entering, helping extend the service life of the components.
Large front axle beam.

Strong and robust with a large structure, built to handle tough operations across all types of terrain.

Convenience

Large operation seat.

Adjustable and ergonomically designed to support the operator’s body, providing greater comfort and reducing fatigue during operation.
Digital display dashboard.

Displays engine RPM, fuel gauge, and operating hours for easy reading. The panel is illuminated with LED backlighting, ensuring clear visibility even at night.
Multi-reflector headlights.

Provides bright illumination that covers the working area, enhancing visibility during nighttime operations.
One-piece engine hood.

Distinctive and stylish design, equipped with a shock absorber to assist in lifting the hood, allowing easy access for inspection and maintenance.
A wide and spacious operator platform for enhanced comfort during operation.

Designed for comfort, enabling continuous operation with less fatigue.

High Value Performance

Support for B20 biodiesel

Save fuel costs by 3.25 Baht per liter, while reducing emissions and being environmentally friendly. It also helps reduce PM2.5 fine dust pollution and supports palm oil farmers.*

Note: Based on the price comparison between B20 biodiesel and B7 diesel on July 1, 2020.

Specifications

Engine specification
Diesel Engine		เครื่องยนต์ดีเซลคูโบต้า แบบเซ็นเตอร์ไดเร็คอินเจ็คชั่น 4 สูบ 4 จังหวะ สูบตั้ง ระบายความร้อนด้วยน้ำ
horsepower	(horsepower)	70.00
Cylinder volume	(cc.)	3,331
Fuel capacity	(liters)	65

Specifications
Type Gear		-
Number of gears		เดินหน้า 8 เกียร์ ถอยหลัง 8 เกียร์
Turning radius (use brakes)	(meter)	3.6
PTO speed (engine rpm)	(rpm)	540 ที่รอบเครื่องยนต์ 2,205
Weight (Tractor only, not including counterweight)	(kilograms)	2,090
Front bumper – rear wheel	(millimeter)	3,445
Width (rim of the rear tire, left-right)	(millimeter)	1,860
Height under the car	(millimeter)	415

Implement M7040-B KIS

Standard implement	Series	Price
Rotary	Rotary RM220	87,000 Baht
Slasher	Slasher SX160	85,000 Baht
Multi Carrier	Multi carrier MCR750+GRABBER(MCR750G)	310,000 Baht
Sugarcane planting machine	Sugarcane planting machine SP621	83,000 Baht
Front dozer	Front dozer FD206J	87,000 Baht
Disc plow	Disc plow DP263J	72,000 Baht
Disc harrow	Disc harrow DH266JW	74,000 Baht
